Creating a cluster with kubeadm

Using kubeadm, you can create a minimum viable Kubernetes cluster that conforms to best practices. In fact, you can use kubeadm to set up a cluster that will pass the Kubernetes Conformance tests. kubeadm also supports other cluster lifecycle functions, such as bootstrap tokens and cluster upgrades.

The kubeadm tool is good if you need:

A simple way for you to try out Kubernetes, possibly for the first time.
A way for existing users to automate setting up a cluster and test their application.
A building block in other ecosystem and/or installer tools with a larger scope.

You can install and use kubeadm on various machines: your laptop, a set of cloud servers, a Raspberry Pi, and more. Whether you're deploying into the cloud or on-premises, you can integrate kubeadm into provisioning systems such as Ansible or Terraform.

Before you begin

To follow this guide, you need:

One or more machines running a deb/rpm-compatible Linux OS; for example: Ubuntu or CentOS.
2 GiB or more of RAM per machine--any less leaves little room for your apps.
At least 2 CPUs on the machine that you use as a control-plane node.
Full network connectivity among all machines in the cluster. You can use either a public or a private network.

You also need to use a version of kubeadm that can deploy the version of Kubernetes that you want to use in your new cluster.

Kubernetes' version and version skew support policy applies to kubeadm as well as to Kubernetes overall. Check that policy to learn about what versions of Kubernetes and kubeadm are supported. This page is written for Kubernetes v1.34.

The kubeadm tool's overall feature state is General Availability (GA). Some sub-features are still under active development. The implementation of creating the cluster may change slightly as the tool evolves, but the overall implementation should be pretty stable.

Note:

Any commands under kubeadm alpha are, by definition, supported on an alpha level.

Objectives

Install a single control-plane Kubernetes cluster
Install a Pod network on the cluster so that your Pods can talk to each other

Instructions

Preparing the hosts

Component installation

Install a container runtime and kubeadm on all the hosts. For detailed instructions and other prerequisites, see Installing kubeadm.

Note:

If you have already installed kubeadm, see the first two steps of the Upgrading Linux nodes document for instructions on how to upgrade kubeadm.

When you upgrade, the kubelet restarts every few seconds as it waits in a crashloop for kubeadm to tell it what to do. This crashloop is expected and normal. After you initialize your control-plane, the kubelet runs normally.

Network setup

kubeadm similarly to other Kubernetes components tries to find a usable IP on the network interfaces associated with a default gateway on a host. Such an IP is then used for the advertising and/or listening performed by a component.

To find out what this IP is on a Linux host you can use:

ip route show # Look for a line starting with "default via"

Note:

If two or more default gateways are present on the host, a Kubernetes component will try to use the first one it encounters that has a suitable global unicast IP address. While making this choice, the exact ordering of gateways might vary between different operating systems and kernel versions.

Kubernetes components do not accept custom network interface as an option, therefore a custom IP address must be passed as a flag to all components instances that need such a custom configuration.

Note:

If the host does not have a default gateway and if a custom IP address is not passed to a Kubernetes component, the component may exit with an error.

To configure the API server advertise address for control plane nodes created with both init and join, the flag --apiserver-advertise-address can be used. Preferably, this option can be set in the kubeadm API as InitConfiguration.localAPIEndpoint and JoinConfiguration.controlPlane.localAPIEndpoint.

For kubelets on all nodes, the --node-ip option can be passed in .nodeRegistration.kubeletExtraArgs inside a kubeadm configuration file (InitConfiguration or JoinConfiguration).

For dual-stack see Dual-stack support with kubeadm.

The IP addresses that you assign to control plane components become part of their X.509 certificates' subject alternative name fields. Changing these IP addresses would require signing new certificates and restarting the affected components, so that the change in certificate files is reflected. See Manual certificate renewal for more details on this topic.

Warning:

The Kubernetes project recommends against this approach (configuring all component instances with custom IP addresses). Instead, the Kubernetes maintainers recommend to setup the host network, so that the default gateway IP is the one that Kubernetes components auto-detect and use. On Linux nodes, you can use commands such as ip route to configure networking; your operating system might also provide higher level network management tools. If your node's default gateway is a public IP address, you should configure packet filtering or other security measures that protect the nodes and your cluster.

Preparing the required container images

This step is optional and only applies in case you wish kubeadm init and kubeadm join to not download the default container images which are hosted at registry.k8s.io.

Kubeadm has commands that can help you pre-pull the required images when creating a cluster without an internet connection on its nodes. See Running kubeadm without an internet connection for more details.

Kubeadm allows you to use a custom image repository for the required images. See Using custom images for more details.

Initializing your control-plane node

The control-plane node is the machine where the control plane components run, including etcd (the cluster database) and the API Server (which the kubectl command line tool communicates with).

(Recommended) If you have plans to upgrade this single control-plane kubeadm cluster to high availability you should specify the --control-plane-endpoint to set the shared endpoint for all control-plane nodes. Such an endpoint can be either a DNS name or an IP address of a load-balancer.
Choose a Pod network add-on, and verify whether it requires any arguments to be passed to kubeadm init. Depending on which third-party provider you choose, you might need to set the --pod-network-cidr to a provider-specific value. See Installing a Pod network add-on.
(Optional) kubeadm tries to detect the container runtime by using a list of well known endpoints. To use different container runtime or if there are more than one installed on the provisioned node, specify the --cri-socket argument to kubeadm. See Installing a runtime.

To initialize the control-plane node run:

kubeadm init <args>

Considerations about apiserver-advertise-address and ControlPlaneEndpoint

While --apiserver-advertise-address can be used to set the advertised address for this particular control-plane node's API server, --control-plane-endpoint can be used to set the shared endpoint for all control-plane nodes.

--control-plane-endpoint allows both IP addresses and DNS names that can map to IP addresses. Please contact your network administrator to evaluate possible solutions with respect to such mapping.

Here is an example mapping:

192.168.0.102 cluster-endpoint

Where 192.168.0.102 is the IP address of this node and cluster-endpoint is a custom DNS name that maps to this IP. This will allow you to pass --control-plane-endpoint=cluster-endpoint to kubeadm init and pass the same DNS name to kubeadm join. Later you can modify cluster-endpoint to point to the address of your load-balancer in a high availability scenario.

Turning a single control plane cluster created without --control-plane-endpoint into a highly available cluster is not supported by kubeadm.

More information

For more information about kubeadm init arguments, see the kubeadm reference guide.

To configure kubeadm init with a configuration file see Using kubeadm init with a configuration file.

To customize control plane components, including optional IPv6 assignment to liveness probe for control plane components and etcd server, provide extra arguments to each component as documented in custom arguments.

To reconfigure a cluster that has already been created see Reconfiguring a kubeadm cluster.

To run kubeadm init again, you must first
